PET Panels - Acoustic Absorption Panels Saudi Arabia
Project Show
Product Introduction
Acoustic Flexible wood is based on a superb craftsmanship that makes wood and wood-based materials flexible so that aesthetics and acoustics are combined. The production process adopts the world’s leading groove cutting technology, which has a great degree of freedom, so as to achieve different effects on both sides. It not only has good acoustic and sound absorption effect, but also breaks through the traditional rigid installation shape. The curved installation effect gives people a unique visual impact, which can be described as another novel material in the acoustic field. Mainly used in auditoriums, conference rooms, multi-purpose halls, classrooms and other places.
*Color and shape customization and other needs, please consult customer service.*
Model Introduction
SNA-DUNA
ACOUSTIC DUNA is special among the cut types cause it only can be made with solid wood. The intersecting cuts mean that the wood can be bent “3-Dimensionally”. The grid-like cut pattern shows squares and has the same appearance on both sides. Production and application are extremely demanding.
Materials :
Solid wood
Standard cut :
4mm groove / 4mm web
Min. bending radius :
approx. 200mm
Standard panel dimensions :
None
Open area :
10% – 20%
Model Introduction
SNA-SONAR
The three-layer panels are provided with a textile middle layer. This can be made of coloured fabric or an acoustically effective felt. This gives the product visual and acoustic added value. ACOUSTIC JANUS TEX is suitable as a free-standing privacy screen and for improving room acoustics.
Materials :
MDF, veneer plywood, blockboard
Standard cut :
4mm groove / 4mm we
Min. bending radius :
approx. 80mm
Standard panel dimensions :
2800mm x 1200mm x 12-42mm
Open area :
20% – 40%
Model Introduction
SNA-FOLI
Panels cut with ACOUSTIC JANUS are suitable for free-standing use because they have the same cutting pattern on both sides. Due to the double-sided cuts, even thick panels can be bent in an amazingly tight radius. The ACOUSTIC JANUS cut type is mainly used for room dividers and privacy screens.
Materials :
MDF, veneer plywood, blockboard
Standard cut :
4mm groove / 4mm web
Min. bending radius :
approx. 80mm
Standard panel dimensions :
2800mm x 1200mm x 12-42mm
Open area :
20% – 40%
Acoustics Test Report
